AL-1235 Rewire For 1600, 1900, 2200, 2700

If you are replacing the alternator on your YM1600, 1900, 2200, or 2700 you will need to hook up the wires according to the attached diagram. The exact "old" style alternator is no longer available.

You can just use regular automotive insulated spade terminals from any local auto parts store for the F and N plug .
